NG-LAVT Panel
Pyrotech’s NG & LAVT Panels are designed to provide effective neutral grounding and voltage transformation, ensuring protection of generators and electrical systems during fault conditions. Construction: Welded Application: Power plant
Product Overview
Pyrotech’s NG & LAVT Panels are engineered to provide safe grounding of electrical systems, particularly in generator applications. These panels house components such as Neutral Grounding Transformer (NGT) and Neutral Grounding Resistor (NGR), which play a critical role in system protection. The Neutral Grounding Transformer steps down the neutral voltage of the generator to lower levels (typically 110V or 220V), which is then passed through a Neutral Grounding Resistor. This process helps bring the neutral voltage close to zero and ensures safe grounding of the system. Neutral Grounding Resistors are used to limit fault current to safe levels, preventing damage to equipment while allowing protective relays to detect and isolate faults effectively. These systems are essential in maintaining system stability, protecting generator windings, and ensuring safe operation during unbalanced load or fault conditions.
By controlling fault currents and stabilizing neutral voltage, NG & LAVT panels enhance system protection, reduce damage risks, and ensure reliable power system performance.
Key Features
Pyrotech’s NG & LAVT Panels are designed to deliver reliable grounding, enhanced protection, and stable operation in critical power systems.
Protection:
IP 54 & IP 55
- 1. These LAVT cubicle are enclosure for HOUSING- Lightening Arrestor (L.A.) Surge Capacitor (S.C.) Voltage Transformers (V.T.)
- 2. NG Cubicle is a enclosure for installations of Neutral Grounding Transformer (N.G.T.) Neutral Grounding Resistance (N.G.R.) Current Transformer (C.T.) Complete with Bus Bar Rack,with Transformers + LA can be optional.
